CIMC-296-01-01-01 Control Box by NuWhirl Systems for Enhanced Performance

CIMC-296-01-01-01 Control Box

The CIMC-296-01-01-01 Control Box from NuWhirl is a purpose-built control module that streamlines tub wiring while expanding what your bath system can do. With two independent channels in a single, compact enclosure, you can manage two separate loads—such as pumps, heaters, or lighting—each up to 15 amps, without the clutter of multiple boxes. The result is cleaner installs, quicker wiring, and more precise control for walk-in tubs and entry-level baths.

Two channels, one compact footprint

• Independent load channels: each supports up to 15 amps at 125 volts AC, 60 Hz
• Compact dimensions: 6-13/16" L x 2-3/8" W x 3" H, designed for tight spaces behind tub enclosures
• Single enclosure, dual control: simplify wiring paths and enclosure routing while delivering dual functionality

LED bath light integration for synchronized ambience

Beyond load control, the CIMC-296-01-01-01 includes built-in LED bath light control. This feature coordinates lighting with bath functions for a cohesive, spa-like experience without the need for extra controllers. It’s a practical touch that enhances relaxation while keeping installation straightforward.

Configurable, plug-in friendly for varied tub systems

• configurable software/firmware to fit a wide range of tub layouts and component configurations
• Designed to adapt to different pump, heater, and lighting setups, making retrofit and new builds faster and more predictable
• Reliable 15A/125V AC per channel rating ensures solid performance across everyday tub applications

Versatile deployment for diverse projects

Whether you’re working on a tight-space walk-in tub or an affordable, multi-zone bath, this dual-load box scales to your needs. Install one CIMC-296-01-01-01 for a basic two-load setup, or deploy two units for expanded capability and more precise, independent control across multiple zones. OEMs and installers alike rely on its predictable behavior in both new builds and retrofit projects.

Why this matters for your tub project

• Simplified wiring: two loads controlled from a single, durable enclosure reduces behind-wall complexity
• Faster installations: streamlined integration with configurable firmware accelerates setup across different tub models
• Consistent lighting and function: LED bath light synchronization creates a cohesive user experience
• Proven reliability: backed by NuWhirl’s focus on quality components, on-time shipping, and attentive support

Ideal for

• Walk-in tub installations needing compact, dual-channel control
• Entry-level baths requiring reliable, multi-load management from a single enclosure
• OEM tub manufacturers and small shops pursuing scalable, modular control solutions
• Retrofits where wiring cleanliness and ease of integration are priorities

Key specifications at a glance

• Independent channels: two loads, up to 15 amps each
• Voltage/frequency: 125 Volts AC, 60 Hz per channel
• Enclosure footprint: 6-13/16" L × 2-3/8" W × 3" H
• LED bath light integration for synchronized lighting with bath functions
• Configurable software/firmware to fit a variety of tub systems

If you’re upgrading a walk-in tub system or designing an entry-level model, the CIMC-296-01-01-01 Dual Load Control Box provides a concrete, capable foundation for clean, efficient control of two separate loads from a single, durable enclosure. It’s a dependable, space-conscious solution that keeps installation straightforward and performance consistent—backed by NuWhirl’s engineering focus and responsive support.
